ChipMusic.org - MIDI-USB adaptor

Re: MIDI-USB adaptor

2018-02-01T20:57:50Z

OK, a little progress. Using the two smaller sides of the cable...

... I get to transfer files between gb and pc, so the cable works (I was using the other conector for the adaptor). I still can't send midi ticks to the gb though. Will keep trying...

Re: MIDI-USB adaptor

2018-02-01T08:42:47Z

oliver wrote:

any gb color/pocket compatile cable.

Oooh, so regular gb color link cable is compatible with gb advance! Didn't know.
Thanks!

Re: MIDI-USB adaptor

2018-01-31T19:36:54Z

any gb color/pocket compatile cable.

Re: MIDI-USB adaptor

2018-01-31T19:24:15Z

About the link cable, I readed some bad reviews about it. Some people saying it worked ok, some people saing it didn't worked at all. I searched and didn't found another similar cable for the GBA, so I ended up buying it, despite that bad reviews, hoping that it would work for me.
I have a DMG-01 too, but no same game carts for that and GBA so I cannot check if it's really cable's problem.
So, someone who has usb-midi adaptor working with GBA could share what link cable is using?

Re: MIDI-USB adaptor

2018-01-31T18:24:33Z

that cable seems fine. gba-multiplayer cables do NOT work.

Re: MIDI-USB adaptor

2018-01-31T18:04:40Z

That link cable you linked to is a DMG/Gameboy Color cable. I've never used the nanoloop usb midi adapter, but you probably need to use a GBA cable. I'd reach out to Oliver to see if he has a known working cable.

Re: MIDI-USB adaptor

2018-01-31T17:58:35Z

Sanju wrote:

Hi, Im trying to synchronize my GBA with Nanoloop and PC, but It's not working. The USB-midi adaptor is in sync mode and I assured myself that the connections between it and usb and link cables are correct:
So I put nanoloop in slave mode, but when I send clock signal from the pc It doesn't seem to receive it, and stays paused. I'm using this cable for the GBA - adaptor connection (http://www.stoneagegamer.com/game-boy-g … tomee.html)
Any clue of what am I doing wrong here?

Well... the data transfer isn't working either and the usb cable is working ok with my mp3, so I suppose that there is a problem with the link cable. Anyone knows about a good game boy advance link cable to use midi-usb adaptor with?

Re: MIDI-USB adaptor

2018-01-31T07:36:44Z

Hi, Im trying to synchronize my GBA with Nanoloop and PC, but It's not working. The USB-midi adaptor is in sync mode and I assured myself that the connections between it and usb and link cables are correct:

So I put nanoloop in slave mode, but when I send clock signal from the pc It doesn't seem to receive it, and stays paused. I'm using this cable for the GBA - adaptor connection (http://www.stoneagegamer.com/game-boy-g … tomee.html)

Any clue of what am I doing wrong here?

Re: MIDI-USB adaptor

2017-03-21T00:41:49Z

cyberic wrote:

e.s.c. wrote:
no, you need an arduinoboy for that. and the earlier ones don't support it without a firmware upgrade
OK, thanks.
I was wondering because of that:
MIDI signals from the Game Boy are forwarded to the PC.
I tested this mode and I nothing shows up in my midi monitor.
Is there a use for this mode?

if you read nitro's post that was after what you quoted, you have your answer

nitro2k01 wrote:

It relies on the GB program to send data formatted as MIDI. There's probably no software today that can actually make use of this functionality. (Trash80's modded LSDj version has a different protocol.) If you wanted to try if it works, I guess you could connect one NL adapter in MIDI out mode to another NL adapter in MIDI in, or an Arduinoboy in MIDI mode to an NL adapter in MIDI in mode to form a loopback.

Re: MIDI-USB adaptor

2017-03-21T00:27:41Z

e.s.c. wrote:

cyberic wrote:
Is it possible to use the adaptor for LSDJ midi out mode?
no, you need an arduinoboy for that. and the earlier ones don't support it without a firmware upgrade

OK, thanks.
I was wondering because of that:

MIDI signals from the Game Boy are forwarded to the PC.

I tested this mode and I nothing shows up in my midi monitor.
Is there a use for this mode?

Re: MIDI-USB adaptor

2017-03-21T00:23:14Z

cyberic wrote:

Is it possible to use the adaptor for LSDJ midi out mode?

no, you need an arduinoboy for that. and the earlier ones don't support it without a firmware upgrade

Re: MIDI-USB adaptor

2017-03-21T00:08:29Z

Is it possible to use the adaptor for LSDJ midi out mode?

Re: MIDI-USB adaptor

2016-11-14T11:19:03Z

Well I am very very appreciative of the ability to at least try out all these nifty MIDI programs using the nanoloop adapter as my one-stop solution. I was getting pretty discouraged seeing how unstandardized and technically complicated all these gameboy music interfaces are, thinking I'd have to go get an engineering degree and break the bank just to be able to make some decent chiptunes with my MIDI keyboard. So you just brought my spirits up immensely!

Re: MIDI-USB adaptor

2016-11-14T11:08:43Z

With that said, I'm not sure Pushpin is the GB MIDI panacea. mGB is probably over all a better solution. But now you have the choice.

Re: MIDI-USB adaptor

2016-11-14T11:00:16Z

HOLY SHIT NITRO2K01 I LOVE YOU!!! after researching and bashing my head in trying to figure out what's what all day, this honestly just made me so happy! thank you so much!!!
